Alternator replacing 104210-2040 / 104210-4670 / 27060-31050
Replacing | |
|---|---|
| 104210-2040 | Denso |
| 104210-4670 | Denso |
| 27060-31050 | Toyota |
| 27060-31051 | Toyota |
| 27060-31060 | Toyota |
| 27060-31062 | Toyota |
More info
Electrical information | |
|---|---|
| Voltage | 14 |
| Amp | 150 |
Catalogue information | |
|---|---|
| Pulley | SP/FW |
| Fan | IF |
| Regulator type | IR |
| Vac. pump | No |
Physical information | ||
|---|---|---|
| A | Pulley dist. | 38.30 |
| B | Width/holder arm | 18.00 |
| C | Mount. bracket dist. | 33.00 |
| D | Bracket hole | 11.00 |
| E | Belt. adj. brackethole pos. | 57 |
| G | Belt. adj. bracket hole | 11.00 |
| G | Belt. adj. bracket hole 2 | M10 |
| H | Pulley dia. | 52.50 |
| I | Grooves/pulley | 7 |
| J | Radius | 84.00 |
| J | Radius 2 | 90.00 |
| K | B+ | M6 |
| K | Position/B+ in min. | 3 |
| N | Rotation | CW |
| O | Plug no. 1 | PL146 |
| R | Total length mm | 176.00 |
| Terminal type | RLO | |
Generic brand
