Alternator NEW replacing VALEO TG8S014 / TG8S016 / TG8S022
Alternator NEW for FIAT, LANCIA, OPEL, SUZUKI,VAUXHALL
= VALEO 2542841 / 2542841A / 2542841B / 2542850 / 2542850A
NO CORE EXCHANGE NEEDED
TWO YEARS WARRANTY
More info
Information:Voltage 14, Amp 75
Physical Information | ||
|---|---|---|
| D | Bracket hole | 9.10 |
| G | Belt. adj. bracket hole | 9.30 |
| B | Width/holder arm | 64.00 |
| C | Mount. bracket dist | 55.00 |
| H | Pulley dia. | 54.10 |
| A | Pulley dist. | 41.50 |
| i | Grooves/pulley | 6 |
| k | Position B + | M8 |
| n | Rotation | Cr |
| o | Plug no. 1 | PL_NA |
| D | Trou from fixation support 2 | 9.30 |
| R | Total length mm | 184.00 |
Replacing | |
|---|---|
| 101210-1110 | DENSO |
| 101210-1111 | DENSO |
| 101210-1180 | DENSO |
| 101210-1181 | DENSO |
| 102211-8610 | DENSO |
| 102211-8611 | DENSO |
| 102211-8612 | DENSO |
| 13117278 | OPEL |
| 13197577 | OPEL |
| 13256930 | OPEL |
| 13283343 | OPEL |
| 2542841 | VALEO |
| 2542841A | VALEO |
| 2542841B | VALEO |
| 2542850 | VALEO |
| 2542850A | VALEO |
| 2542850C | VALEO |
| 2542883 | VALEO |
| 2543480 | VALEO |
| 2543480A | VALEO |
| 2543481 | VALEO |
| 2606333 | VALEO |
| 2606333A | VALEO |
| 31400-85E00 | SUZUKI |
| 51718499 | FIAT |
| 51787208 | FIAT |
| 51805799 | FIAT |
| 51854909 | FIAT |
| 51854914 | FIAT |
| 6204180 | OPEL |
| 6204664 | OPEL |
| 63377493 | MAGNETI MARELLI |
| 93169026 | OPEL |
| ca1855ir | HC-PARTS |
| TG8S012 | VALEO |
| TG8S013 | VALEO |
| TG8S014 | VALEO |
| TG8S016 | VALEO |
| TG8S022 | VALEO |
| TG8S023 | VALEO |
Generic brand
NO CORE EXCHANGE NEEDED
TWO YEARS WARRANTY
