Alternator replacing BOSCH 0120489952 / 0120489951 / 0120489950

Information:

Voltage 14

Amp 55

Plug type W

D = Bracket hole 8.20

G = Belt. adj. bracket hole 8.20

B = Width/holder arm 56.00

E = Belt. adj. brackethole pos. 57

E = Belt. adj. brackethole pos. 60

H = Pulley dia. 72.00

A = Pulley dist. 84.00

Grooves/pulley 1

J = Radius 85.75

J = Radius 88.00

J = Radius 87.50

Position B + M6

Rotation Cr

Plug no. 1 PL_NA

Fan Ef

Pulley Pulley

G = Belt. adj. bracket hole 8.20

R = Total length mm 170.00

generic brand

= BOSCH 0120489952 / 0120489951 / 0120489950 / 0120489948 / 0120489947 / 0120489125 / 0120489124 / 0120489123

= ISKRA AAK4133 / AAK3129 / 11.201.927 / 11.201.299

= MAGNETON 9516761 / 9516760 / 9516716 / 443113516761

= DELCO REMY 719 / 619 / 3493719 / 3493619 / 3472208 / 3472066 / 3472051 / 208 / 066 / 051

= VALEO A13N214 / 2541341

= OPEL 1204004 / 1204005 / 1204013 / 1204222 / 1204316 / 1204321 / 1204335 / 90337045 / 90349207

               NO CORE EXCHANGE NEEDED

                                  TWO YEARS WARRANTY
