Alternator NEW for CITROEN, FIAT, LANCIA
= DENSO 102211-8440 / 102211-8431 / 102211-8430 / 102211-8230
= FIAT 46542889 / 46843091 / 51709133 / 51714794 / 51859037
= MAGNETI MARELLI 63321718 / 63377002 / 63377006 / 63377008
NO CORE EXCHANGE NEEDED
TWO YEARS WARRANTY
Information:
Voltage 14 - Amp 70
Physical Information | ||
|---|---|---|
| D | Bracket hole | 8.50 |
| G | Belt. adj. bracket hole | 8.50 |
| B | Width/holder arm | 23.50 |
| C | Mount. bracket dist | 50.00 |
| H | Pulley dia. | 53.00 |
| A | Pulley dist. | 16.50 |
| i | Grooves/pulley | 5 |
| k | Position B + | M8 |
| n | Rotation | Cr |
| o | Plug no. 1 | PL_NA |
| D | Trou from fixation support 2 | 8.60 |
| R | Total length mm | 184.60 |
Replacing | |
|---|---|
| 102211-8230 | DENSO |
| 102211-8430 | DENSO |
| 102211-8431 | DENSO |
| 102211-8440 | DENSO |
| 102211-8441 | DENSO |
| 46542889 | FIAT |
| 46843091 | FIAT |
| 51709133 | FIAT |
| 51714794 | FIAT |
| 51859037 | FIAT |
| 52003531 | FIAT |
| 63321718 | MAGNETI MARELLI |
| 63377002 | MAGNETI MARELLI |
| 63377006 | MAGNETI MARELLI |
| 63377008 | MAGNETI MARELLI |
| ca1766ir | HC-PARTS |
NO CORE EXCHANGE NEEDED
TWO YEARS WARRANTY
The reference number of your defective part is essential to determine the right replacement part. Each brand has its own nomenclature for authenticating its spare parts.
The part number can be numeric or alphanumeric, and can be found on your part.
Once you've found the part number, enter it in the search bar at the top center of our site.
The result will be the replacement part matching your part number.
