Solenoid for starter BOSCH 0001107033 / 0001108070 / 0001108103
Solenoid for starter BOSCH 0001107033 / 0001108070 / 0001108103 / 0001108104 / 0001108105 / 0001108129 / 0001108134 / 0001108135 / 0001108995 / 0001108996 / 9007045007 / 9007045019 / 9007046007 / 9007046008
More info
Information:
Electrical Information | ||
|---|---|---|
| Voltage | 12 | |
Physical Information | ||
|---|---|---|
| A | DE mm | 56.30 |
| B | Total length mm | 140.55 |
Support | ||
|---|---|---|
| M | Bolt Coil | M8 |
| D | OD/cover mm | 49.75 |
| E | DI capot mm | 27.00 |
| G | B+ | M8 |
| H | Height/B+ | 19.80 |
| K | Kl. 50/mm | M5 |
| N | Bolt Coil l. | 12.25 |
| L | Height/kl. 50 | 17.60 |
| No./terminals | 3 | |
Replacing | |
|---|---|
| 0331303137 | BOSCH |
| 0331303169 | BOSCH |
| 2339303208 | BOSCH |
| zm-675 | ZM |
generic brand
for starter BOSCH :
0001107033
0001108070
0001108103
0001108104
0001108105
0001108129
0001108134
0001108135
0001108995
0001108996
9007045007
9007045019
9007046007
9007046008
