Rectifier for alternator DENSO 104210-3240 / 104210-3710 / 104210-3711
for alternator Denso 104210-1060, 104210-1240, 104210-2910, 104210-2950, 104210-3690, 104210-3710, 104210-3711, 104210-3770, 104210-4000, 104210-4001, 104210-4290, 104210-4420, 104210-4421, 104210-4480, 104210-4481, 104210-4690, 104210-5910, 104210-5920, 104210-5970, 9764219-124, TN104210-2950, TN104210-4690
More info
generic brand
Physical information | ||
|---|---|---|
| A | OD mm | 115.50 |
| D | B+/threaded | M8/12.50 |
| Diode | w/o | |
| Diode Trio | w/o | |
| No. of diodes | 12 | |
Electrical information | ||
|---|---|---|
| Diode A | 30 | |
for alternator
Acura 31100-RGL-A01, 31100-RGL-A01RM, 31100-RGW-A01, 31100-RGW-A01RM, 31100-RJA-A01, 31100-RJA-A02, CSD29, CSD69, CSF92
Denso 104210-1060, 104210-1240, 104210-2910, 104210-2950, 104210-3690, 104210-3710, 104210-3711, 104210-3770, 104210-4000, 104210-4001, 104210-4290, 104210-4420, 104210-4421, 104210-4480, 104210-4481, 104210-4690, 104210-5910, 104210-5920, 104210-5970, 9764219-124, TN104210-2950, TN104210-4690; Ford 5178833, 9L3T-10300-CB, 9L3Z-10346-C, AL1Z-10346-A, BR3Z-10346-E, DS7Z-10346-D; Ford Engineering 9L3T-CB, BR3T-10300-LA, DS7T-10300-DB
GM 10355395, 12582024, 84009358; Honda 06311-RCB-505RM, 06311-RV0-505RM, 31100-R70-A01, 31100-R70-A01RM, 31100-RCB-505RM, 31100-RCB-Y02, 31100-RDM-A01, 31100-RDM-A01RM, 31100-RGL-A01, 31100-RGL-A01RM, 31100-RGW-A01, 31100-RGW-A01RM, 31100-RJA-A01, 31100-RJA-A02, 31100-RV0-A01, 31100-RV0-A01RM, CSC77, CSD29, CSD48, CSD69, CSF91, CSF92, CSJ24; Hyundai 37300-2F200;
Land Rover YLE500190, YLE500190E, YLE500200, YLE500390, YLE500400; Lexus 27060-50340, 27060-50340-84
Toyota 27060-50340
