Rectifier for alternator LUCAS
| 24206 |
| 24206A |
| 24206A/B |
| 24206B |
| 24207 |
| 24207A |
| 24216 |
| 24217 |
| 24217A |
| 24220 |
| 24220A |
| 24221 |
| 24221A |
| 24271 |
| 54022158 |
| 54022159 |
| 54022187 |
| 54022232 |
Information:
B+ type Vis
A = DE mm 115.00
B = DI mm 48.15
J = Mount. dist. 71.50
D = B+/Thread M6
F = D+/Threaded M4
H = Thread W M5/25.50
Diode type Hd
Capacitor Without
Plug D+ Vis
Tipo W Vis
For A127
Diode A 35
Number of Diodes 6
generic brand
replacing
= LUCAS ubb137 / 84886 / 84469 / 000084886010 / 000084469010
= MAGNETI MARELLI 28502
fits alternator :
| A4012 | AS-PL | 54022197 | MAGNETI MARELLI |
| A4013 | AS-PL | 54022198 | MAGNETI MARELLI |
| A4041 | AS-PL | 54022275 | MAGNETI MARELLI |
| 1012257 | FORD | 54022340 | MAGNETI MARELLI |
| 1659058 | FORD | 54022474 | MAGNETI MARELLI |
| 5027845 | FORD | 54022574 | MAGNETI MARELLI |
| 5029923 | FORD | 54022665 | MAGNETI MARELLI |
| 88BB10300HA | FORD | 54022693 | MAGNETI MARELLI |
| 88BB10300HB | FORD | 63324121 | MAGNETI MARELLI |
| 89FF10300CC | FORD | 63324206 | MAGNETI MARELLI |
| 89FF10300CD | FORD | 63324217 | MAGNETI MARELLI |
| 89FF10300CE | FORD | 63324220 | MAGNETI MARELLI |
| 89FF10300EB | FORD | 63324221 | MAGNETI MARELLI |
| 89FF10300EC | FORD | 63324334 | MAGNETI MARELLI |
| 89FF10300JA | FORD | 63324404 | MAGNETI MARELLI |
| 89FF10300JB | FORD | 2871A161 | PERKINS |
| 89FX10300CD | FORD | 2871A161 | PERKINS |
| 89FX10300EB | FORD | 54022314B | LUCAS |
| 89FX10300JA | FORD | 54022317 | LUCAS |
| 91FF10300TA | FORD | 54022318 | LUCAS |
| 95FB10300AA | FORD | 54022330 | LUCAS |
| V89AB10300AA | FORD | 54022388 | LUCAS |
| 054022197010 | LUCAS | 54022400 | LUCAS |
| 054022198010 | LUCAS | 54022419 | LUCAS |
| 054022232010 | LUCAS | 54022450 | LUCAS |
| 054022251010 | LUCAS | 54022514 | LUCAS |
| 054022275010 | LUCAS | 54022559 | LUCAS |
| 054022290010 | LUCAS | 54022584 | LUCAS |
| 054022314010 | LUCAS | 54022585 | LUCAS |
| 054022317010 | LUCAS | 54022597 | LUCAS |
| 054022330010 | LUCAS | 54022602 | LUCAS |
| 054022340010 | LUCAS | 54022603 | LUCAS |
| 054022388010 | LUCAS | 54022604 | LUCAS |
| 054022419010 | LUCAS | 54022614 | LUCAS |
| 054022474010 | LUCAS | 54022701 | LUCAS |
| 054022514010 | LUCAS | 54022716 | LUCAS |
| 054022574010 | LUCAS | 54055205 | LUCAS |
| 054022585010 | LUCAS | LRA00517 | LUCAS |
| 054022602010 | LUCAS | LRA00604 | LUCAS |
| 054022603010 | LUCAS | LRA517 | LUCAS |
| 054022604010 | LUCAS | LRA604 | LUCAS |
| 054022665010 | LUCAS | ||
| 054022693010 | LUCAS | ||
| 063324206010 | LUCAS | ||
| 063324217010 | LUCAS | ||
| 063324220010 | LUCAS | ||
| 063324221010 | LUCAS | ||
| 063324404010 | LUCAS | ||
| 24206 | LUCAS | ||
| 24206A | LUCAS | ||
| 24206A/B | LUCAS | ||
| 24206B | LUCAS | ||
| 24207 | LUCAS | ||
| 24207A | LUCAS | ||
| 24216 | LUCAS | ||
| 24217 | LUCAS | ||
| 24217A | LUCAS | ||
| 24220 | LUCAS | ||
| 24220A | LUCAS | ||
| 24221 | LUCAS | ||
| 24221A | LUCAS | ||
| 24271 | LUCAS | ||
| 54022158 | LUCAS | ||
| 54022159 | LUCAS | ||
| 54022187 | LUCAS | ||
| 54022232 | LUCAS | ||
| 54022251 | LUCAS | ||
| 54022281 | LUCAS | ||
| 54022290 | LUCAS | ||
| 54022305 | LUCAS | ||
| 54022307 | LUCAS | ||
| 54022312 | LUCAS | ||
| 54022314 | LUCAS |
The reference number of your defective part is essential to determine the right replacement part. Each brand has its own nomenclature for authenticating its spare parts.
The part number can be numeric or alphanumeric, and can be found on your part.
Once you've found the part number, enter it in the search bar at the top center of our site.
The result will be the replacement part matching your part number.
