Rectifier for alternator BOSCH 0120450010 / 0120450015 / 0120468065
Rectifier for alternator BOSCH 0120450010, 0120450015,0120468065, 0120468066, 0120468094,
0120468116, 0120468124, 0120468129,0120468130, 0120468139, 0124469999
More info
Electrical information | ||
|---|---|---|
| Diode A | 40 | |
Physical information | ||
|---|---|---|
| A | OD mm | 124.00 |
| B | ID mm | 36.40 |
| J | Mount. dist. | 53.00 |
| B+ type | Screw | |
| D | B+/threaded | M8/33.00 |
| E | B+ | M8 |
| D+ type | Screw | |
| F | D+ threaded | M6/33.00 |
| G | D+ | M6 |
| L | B- | M6 |
| W type | Screw | |
| H | W thread | M5/23.20 |
| Diode | w/ | |
| Brush gear | w/o | |
| Terminals | 4 | |
| Diode Trio | w/ | |
| No. of diodes | 14 | |
generic brand
replacing
1127320995, 1127320969,1127320961, 1127320959, 1127320946,
1127320928, 1127320656, 1127320655
for alternator :
| A0108 | AS-PL | 0120469798 | BOSCH |
| 0120450010 | BOSCH | 0120469807 | BOSCH |
| 0120450015 | BOSCH | 0120469843 | BOSCH |
| 0120468066 | BOSCH | 0120469850 | BOSCH |
| 0120468094 | BOSCH | 0120469851 | BOSCH |
| 0120468116 | BOSCH | 0120469852 | BOSCH |
| 0120468124 | BOSCH | 0120469853 | BOSCH |
| 0120468129 | BOSCH | 0120469854 | BOSCH |
| 0120468130 | BOSCH | 0120469855 | BOSCH |
| 0120468139 | BOSCH | 0120469891 | BOSCH |
| 0120468146 | BOSCH | 0120469900 | BOSCH |
| 0120468159 | BOSCH | 0120469905 | BOSCH |
| 0120468160 | BOSCH | 0120469920 | BOSCH |
| 0120468162 | BOSCH | 0120469951 | BOSCH |
| 0120468999 | BOSCH | 0120469952 | BOSCH |
| 0120469008 | BOSCH | 0120469955 | BOSCH |
| 0120469010 | BOSCH | 0120469956 | BOSCH |
| 0120469014 | BOSCH | 0120469959 | BOSCH |
| 0120469019 | BOSCH | 0120469960 | BOSCH |
| 0120469022 | BOSCH | 0120469978 | BOSCH |
| 0120469023 | BOSCH | 0120469999 | BOSCH |
| 0120469025 | BOSCH | 6033G3030B | BOSCH |
| 0120469026 | BOSCH | 6033G3031B | BOSCH |
| 0120469027 | BOSCH | 6033G3037B | BOSCH |
| 0120469030 | BOSCH | 6033G3038B | BOSCH |
| 0120469031 | BOSCH | 6033G3039B | BOSCH |
| 0120469038 | BOSCH | 6033G3040B | BOSCH |
| 0120469039 | BOSCH | 6033G3043B | BOSCH |
| 0120469048 | BOSCH | 6033G3045B | BOSCH |
| 0120469104 | BOSCH | 6033GB3031 | BOSCH |
| 0120469105 | BOSCH | 6033GB3040 | BOSCH |
| 0120469518 | BOSCH | 6033GB3045 | BOSCH |
| 0120469519 | BOSCH | 6033GB3048 | BOSCH |
| 0120469520 | BOSCH | B120421831 | BOSCH |
| 0120469521 | BOSCH | B120421892 | BOSCH |
| 0120469522 | BOSCH | 1105367 | SCANIA |
| 0120469523 | BOSCH | 571516 | SCANIA |
| 0120469526 | BOSCH | ALT0101 | UNIPOINT |
| 0120469527 | BOSCH | ||
| 0120469532 | BOSCH | ||
| 0120469540 | BOSCH | ||
| 0120469562 | BOSCH | ||
| 0120469569 | BOSCH | ||
| 0120469579 | BOSCH | ||
| 0120469580 | BOSCH | ||
| 0120469585 | BOSCH | ||
| 0120469592 | BOSCH | ||
| 0120469629 | BOSCH | ||
| 0120469630 | BOSCH | ||
| 0120469652 | BOSCH | ||
| 0120469653 | BOSCH | ||
| 0120469692 | BOSCH | ||
| 0120469749 | BOSCH | ||
| 0120469752 | BOSCH | ||
| 0120469753 | BOSCH | ||
| 0120469761 | BOSCH | ||
| 0120469763 | BOSCH | ||
| 0120469772 | BOSCH | ||
| 0120469773 | BOSCH | ||
| 0120469797 | BOSCH |
