w113933

Starter for CITROEN, Mini, PEUGEOT, TOYOTA

= CITROEN 5802AA / 5802EG / 5802Z8 / 5802Z9 / 9645100680 / 9645100680

= Cevam 3105

= DELCO REMY drs3976

= LUCAS LRS1737

= TOYOTA 28100-YV020

= VALEO D7G3 / 438166 / 458185

Origine VALEO under the reference W220524113

Read more
€89.90 Tax included
Price may vary according to your VAT rate
Fast delivery
Add product to favorites
2-year warranty
No instructions, no return of the old
Secure payments

Reference

02T911023Q

Volkswagen AG

0986022790

Bosch Exchange

0986022791

Bosch Exchange

113933

HC-Cargo

14130152

AES

14130187

AES

190895

Valeo

193767

Valeo

1986S01015

Bosch

220524113

PSH

2605406000

Denso

2605406180

Denso

28100YV020

Toyota

3110073J00

Suzuki

32737N

WAI

32737R

WAI

438166

Valeo

458185

Valeo

495107

Valeo

5645100680

PSA

580228

PSA

580229

PSA

5802AA

PSA

5802EG

PSA

5802Z8

PSA

5802Z9

PSA

5802ZB

PSA

63721329010

Magneti Marelli

71794297

Fiat Group

726065

Valeo

726865

Valeo

944280801170

Magneti Marelli

9645100680

PSA

9662854080

PSA

9663528880

PSA

966352888001

PSA

966401698001

PSA

9801667780

PSA

980166778000

PSA

CS1329

HC-Parts

D7G3

Valeo

DRS3976

Delco Remy

DSN3019

Denso

DSN3038

Denso

F032113933

HC-Cargo

F042S0H117

Bosch

HCS1329

HC-Parts

LES0246

Lucas

LRS01737

Lucas

LRS1737

Lucas

MRS80117

Magneti Marelli

OSM11090

Optimum

RAS34087

Delco Remy

RNLD7G3

RNL

RNLTS18E13

RNL

STR4620

Unipoint

STR54044

Wood Auto

STR71123

Wood Auto

STRH117

Unipoint

TS18E013

Valeo

TS18E13

Valeo

TT16374PRO

Tesla Technics

VAL438166

Wood Auto

VALTS18E13

Wood Auto

WOOSTR54044

Wood Auto

WOOSTR71123

Wood Auto

Features

Information:

Voltage 12 - KW 1.5

Physical Information
E Mounting holes 9.00
E Mounting holes 2 M8
E Mounting holes 3 M8
E Mounting holes 4 9.00
B Drive distance 14.00
F Distance / Back 159.00
G Distance / Front 53.00
H Nbr of teeth 11
I B+ M8
N Gear type Gr
O Distance mm 125.50
O Distance 2 29.50
O Distance 3 47.50
O Distance 4 91.50
P Rotation Cr
R Total length mm 220.00

generic brand

= CITROEN 5802AA / 5802EG / 5802Z8 / 5802Z9 / 9645100680 / 9645100680

= DELCO REMY drs3976

= LUCAS LRS1737

= PEUGEOT 9645100680 / 9662854080 / 9663528880 / 9801667780 / 5802aa / 5802eg / 5802z8 / 5802z9

= TOYOTA 28100-YV020

= VALEO 190895 / 438166 / 458185 / D7G3  / TS18E13

 There may be several different starter motor configurations for a single vehicle; therefore, to avoid any mismatches, it is recommended that you use the part number of the old starter motor as a reference.

Fits the following vehicles

  • SUZUKI

    • LIANA Break (ER) 1.4 ddis 90cv

    • LIANA (ER, RH_) 1.4 ddis 90cv

  • PEUGEOT

    • 206 3/5 s (2A/C) 1.4 hdi eco 70 68cv , 1.4 hdi 69cv

    • 206 CC (2D) 1.6 hdi 110 109cv

    • 307 (3A/C) 1.6 hdi 110 109cv , 1.6 hdi 90cv

    • 307 SW (3H) 1.6 hdi 110 109cv , 1.6 hdi 90 90cv

    • 206 SW (2E/K) 1.4 hdi 68cv

    • 407 (6D_) 1.6 hdi 110 109cv

    • 307 Break (3E) 1.6 hdi 110 109cv , 1.6 hdi 90cv

    • 407 SW (6E_) 1.6 hdi 110 109cv

    • 1007 (KM_) 1.4 hdi 68cv

    • 107 1.4 hdi 54cv

    • 207 (WA_, WC_) 1.6 hdi 90cv , 1.6 hdi 109cv , 1.4 hdi 68cv , 1.6 hdi 92cv , 1.6 hdi 110 112cv

    • 206 A trois volumes 1.4 hdi eco 70 68cv

    • 207 CC (WD_) 1.6 hdi 109cv , 1.6 hdi 112cv

    • EXPERT Tepee (VF3V_) 1.6 hdi 90 8v 90cv

    • EXPERT Camionnette (VF3A_, VF3U_, VF3X_) 1.6 hdi 90 8v 90cv

    • 308 (4A_, 4C_) 1.6 hdi 90cv , 1.6 hdi 109cv , 1.6 hdi 112cv , 1.6 hdi 114cv

    • 207 SW (WK_) 1.6 hdi 90cv , 1.6 hdi 109cv , 1.6 hdi 112cv , 1.6 hdi 92cv

    • PARTNER Tepee 1.6 hdi 90 92cv , 1.6 hdi 16v 90cv , 1.6 hdi 109cv , 1.6 hdi 112cv , 1.6 hdi 114cv , 1.6 hdi 90cv , 1.6 bluehdi 100 100cv , 1.6 bluehdi 120 120cv , 1.6 bluehdi 75 75cv

    • PARTNER Camionnette 1.6 hdi 90 92cv , 1.6 hdi 112cv , 1.6 hdi 16v 90cv , 1.6 hdi 109cv , 1.6 hdi 114cv , 1.6 hdi 90cv , 1.6 bluehdi 100 100cv , 1.6 bluehdi 120 120cv , 1.6 hdi / bluehdi 75 75cv

    • 308 SW 1.6 hdi 109cv , 1.6 hdi 112cv , 1.6 hdi 114cv

    • 308 CC 1.6 hdi 112cv , 1.6 hdi 114cv

    • 3008 1.6 hdi 109cv , 1.6 hdi 112cv , 1.6 hdi 114cv

    • 5008 1.6 hdi 112cv , 1.6 hdi 110cv , 1.6 hdi 114cv

    • 207 Van 1.4 hdi 68cv

    • 206+ (T3E) 1.4 hdi eco 70 68cv

    • 508 1.6 hdi 112cv , 1.6 hdi 115cv

    • 508 SW 1.6 hdi 112cv , 1.6 hdi 115cv

    • PARTNER Camion plate-forme/Châssis 1.6 hdi 90cv

    • 206 Van 1.4 hdi 68cv

    • 208 1.4 hdi 68cv , 1.6 hdi 114cv

    • 2008 1.6 hdi 114cv , 1.4 hdi 68cv

    • 308 II 1.6 hdi 92cv , 1.6 hdi / bluehdi 115 115cv

    • 308 SW II 1.6 hdi 92 92cv , 1.6 hdi / bluehdi 115 115cv

  • TOYOTA

    • AYGO (WNB1_, KGB1_) 1.4 hdi 54cv

  • CITROËN

    • BERLINGO (MF) 1.6 hdi 110 109cv

    • XSARA PICASSO (N68) 1.6 hdi 109cv

    • C3 I (FC_) 1.4 hdi 70cv , 1.4 hdi 68cv , 1.4 16v hdi 90cv , 1.6 16v hdi 109cv

    • C3 Pluriel (HB_) 1.4 hdi 68cv

    • C2 (JM_) 1.4 hdi 68cv

    • C4 Coupé (LA_) 1.6 hdi 90cv , 1.6 hdi 109cv

    • C4 I (LC_) 1.6 hdi 90cv , 1.6 hdi 109cv

    • C1 (PM_, PN_) 1.4 hdi 54cv

    • C4 Picasso I (UD_) 1.6 hdi 110 112cv , 1.6 hdi 109cv

    • JUMPY 1.6 hdi 90 8v 90cv

    • JUMPY Camionnette 1.6 hdi 90 8v 90cv

    • C4 Grand Picasso I (UA_) 1.6 hdi 110 112cv , 1.6 hdi 109cv

    • C5 III (RD_) 1.6 hdi 110 109cv , 1.6 hdi 110 112cv , 1.6 hdi 115 114cv

    • C5 III Break (TD_) 1.6 hdi 110 109cv , 1.6 hdi 110 112cv , 1.6 hdi 115 114cv

    • BERLINGO (B9) 1.6 hdi 90 92cv , 1.6 hdi 110 109cv , 1.6 hdi 110 112cv , 1.6 hdi 115 114cv , 1.6 bluehdi 100 99cv , 1.6 bluehdi 75 75cv

    • BERLINGO Camionnette (B9) 1.6 hdi 90 92cv , 1.6 hdi 110 112cv , 1.6 hdi 110 109cv , 1.6 hdi 115 114cv , 1.6 bluehdi 100 99cv , 1.6 hdi / bluehdi 75 75cv , 1.6 hdi 90 90cv

    • C3 Picasso 1.6 hdi 110 112cv , 1.6 hdi 109cv , 1.6 hdi 115 114cv

    • C3 II 1.6 hdi 92cv , 1.4 hdi 70 68cv

    • DS3 1.4 hdi 70 68cv , 1.6 hdi 90 92cv , 1.6 hdi 110 112cv , 1.6 hdi 115 114cv

    • C4 A trois volumes 1.6 hdi 109cv

    • C2 ENTERPRISE 1.4 hdi 68cv

    • C4 II (B7) 1.6 hdi 90 92cv , 1.6 hdi 110 112cv , 1.6 hdi 115 114cv , 1.6 bluehdi 120 120cv

    • DS4 1.6 thp 200 200cv , 1.6 hdi 110 112cv , 1.6 hdi 110 110cv , 1.6 hdi 115 114cv , 1.6 hdi 90 92cv , 1.6 bluehdi 120 120cv

    • DS5 1.6 hdi 110 112cv , 1.6 hdi 115 114cv

    • DS3 Décapotable 1.6 hdi 90 92cv

    • C4 Picasso II 1.6 hdi 90 92cv , 1.6 hdi / bluehdi 115 115cv

    • C4 Grand Picasso II 1.6 hdi 90 92cv , 1.6 hdi / bluehdi 115 115cv



                              NO CORE EXCHANGE NEEDED
