Electrical information |
||
|---|---|---|
| Voltage | 12 | |
| Kw | 0.7 | |
| 270.4.005.1A | DUCATI |
| 30799 | LESTER |
| 30799N | WAI / TRANSPO |
| 428000-1070 | DENSO |
| UD102726S | AS-PL |
| 116076 | CARGO |
| 400.921.133.260 | PSH |
| STN1828 | KRAUF |
| STR70479 | WOODAUTO |
| F032116076 | CARGO |
| 270.4.005.1A | DUCATI |
| 30799 | LESTER |
| 30799N | WAI / TRANSPO |
| 428000-1070 | DENSO |
| UD102726S | AS-PL |
| 116076 | CARGO |
| 400.921.133.260 | PSH |
| STN1828 | KRAUF |
| STR70479 | WOODAUTO |
| F032116076 | CARGO |
Physical information |
||
|---|---|---|
| H | No./teeth | 13 |
| P | Rotation | CCW |
| N | Gear type | DD |
| A | Mount. flange | 50,00 |
| I | B+ | M6 |
| No./mount. holes | 3 (3) | |
| B | Drive dist. | 27,50 |
| E | Mount. holes | M6 |
| E | Mount. hole 2 | M6 |
| E | Mount. hole 3 | M6 |
| F | Dist./back | 127,00 |
| G | Dist./front | 32,00 |
| O | Dist. mm | 59,20 |
| O | Dist. 2 | 47.20 |
| O | Dist. 3 | 57,80 |
| R | Total length mm | 166,00 |
generic brand
SND0669
| Brand | Model | Typ | Year |
| DUCATI | 1000 1000 DS | 01.2005 - 12.2006 | |
| DUCATI | 1000 1000 SS | 01.2004 - 12.2004 | |
| DUCATI | 1000 1000 SS Carenata (V5) | 01.2003 - 12.2003 | |
| DUCATI | 1000 1000 SS Nuda (V5) | 01.2003 - 12.2003 | |
| DUCATI | 1098 1098 | 01.2008 - 12.2008 | |
| DUCATI | 1098 1098 R (H7) | 01.2008 - 12.2008 | |
| DUCATI | 1098 1098 R Bayliss Limited Edition | 01.2009 - 12.2009 | |
| DUCATI | 1098 1098 S | 01.2008 - 12.2008 | |
| DUCATI | 749 749 (H 5) | 11.2002 - 12.2006 | |
| DUCATI | 749 749 Dark | 11.2003 - 12.2006 | |
| DUCATI | 749 749 R (H5) | 11.2003 - 12.2006 | |
| DUCATI | 749 749 S | 11.2003 - 12.2006 | |
| DUCATI | 749 749 S (H 5) | 11.2003 - 12.2003 | |
| DUCATI | 998 998 | 01.2001 - 12.2004 | |
| DUCATI | 999 999 | 01.2006 - 12.2006 | |
| DUCATI | 999 999 | 01.2003 - 12.2005 | |
| DUCATI | 999 999 R | 01.2004 - 12.2006 | |
| DUCATI | 999 999 R | 01.2006 - 12.2006 | |
| DUCATI | 999 999 R Xerox | 01.2006 - 12.2006 | |
| DUCATI | 999 999 S | 01.2003 - 12.2005 | |
| DUCATI | GT GT 1000 | 01.2006 - 12.2010 | |
| DUCATI | GT GT 1000 Touring | 01.2009 - 12.2009 | |
| DUCATI | GT GT 1000 Touring | 01.2006 - 12.2008 | |
| DUCATI | MILLE Mille 1000 MHR | 01.1985 - 12.1985 | |
| DUCATI | MILLE Mille 1000 S2 | 01.1985 - 12.1985 | |
| DUCATI | MONSTER (900cc - ) Monster 1000 | 01.2004 - 12.2005 | |
| DUCATI | MONSTER (900cc - ) Monster 1000 Dark | 01.2003 - 12.2003 | |
| DUCATI | MONSTER (900cc - ) Monster 1000 S | 01.2003 - 12.2005 | |
| DUCATI | MONSTER (900cc - ) Monster S2R 1000 | 01.2006 - 12.2008 | |
| DUCATI | MONSTER (900cc - ) Monster S4 | 01.2001 - 12.2005 | |
| DUCATI | MONSTER (900cc - ) Monster S4R | 01.2004 - 12.2008 | |
| DUCATI | MONSTER (900cc - ) Monster S4RS | 01.2006 - 12.2008 | |
| DUCATI | MONSTER (900cc - ) Monster S4RS Tricolore | 01/01/08 | |
| DUCATI | MULTISTRADA Multistrada 1000 DS | 01.2003 - 12.2006 | |
| DUCATI | MULTISTRADA Multistrada 1000 DS | 01/01/06 | |
| DUCATI | MULTISTRADA Multistrada 1000 S DS | 01.2003 - 12.2006 | |
| DUCATI | PAUL SMART Paul Smart 1000LE | 01.2006 - 12.2006 | |
| DUCATI | SPORT Sport 1000 | 01.2006 - 12.2008 | |
| DUCATI | SPORT Sport 1000 S | 01.2007 - 12.2009 | |
| DUCATI | ST ST 3 | 01.2006 - 12.2007 | |
| DUCATI | ST ST 3 | 01.2004 - 12.2005 | |
| DUCATI | ST ST 3S ABS | 01.2006 - 12.2007 | |
| DUCATI | ST ST 4 | 01.1998 - 12.2003 | |
| DUCATI | ST ST 4 S (S2, S3) | 01.2001 - 12.2005 |
The reference number of your defective part is essential to determine the right replacement part. Each brand has its own nomenclature for authenticating its spare parts.
The part number can be numeric or alphanumeric, and can be found on your part.
Once you've found the part number, enter it in the search bar at the top center of our site.
The result will be the replacement part matching your part number.
