w18310n

Starter replacing

HITACHI S108-80, S108-80A, S108-80B, S108-80BN

MERCURY MARINE 50-814980M, 50-96359M, 50-97693M,

YAMAHA 689-81800-11, 689-81800-11-00, 689-81800-12, 689-81800-12-00, 689-81800-13, 689-81800-13-00

NO CORE EXCHANGE NEEDED

TWO YEARS WARRANTY

€99.90 Tax included
Price may vary according to your VAT rate
Last items in stock Fast delivery
2-year warranty
No instructions, no return of the old
Secure payments

Références

689-81800-11 YAMAHA
18310 LESTER
18310N WAI / TRANSPO
71-25-18310 WILSON
SHI0085 ARROWHEAD
240-06103 DIXIE
HT2-0055N JUST PARTS
50-814980M MERCURY MARINE
50-96359M MERCURY MARINE
50-97693M MERCURY MARINE
RS41149 DELCO
2-2309-HI WAI / TRANSPO
689-81800-11-00 YAMAHA
689-81800-12 YAMAHA
689-81800-12-00 YAMAHA
689-81800-13 YAMAHA
689-81800-13-00 YAMAHA
STH6359 KRAUF
114675 CARGO
S108-80 HITACHI
S108-80A HITACHI
S108-80B HITACHI
S108-80BN HITACHI
970.021.112.080 PSH
10439338 ALANKO
3127597 HENKEL PARTS
TT16735 TESLA
104-10371NOE ROBERT'S
104-10371 ROBERT'S
10020205AV ITAB AUTOMOTIVE
CST20205AS CASCO
CST20205GS CASCO
255053 KUHNER
20445502BN REAL
20445502OE REAL
6020205.0 SANDO
6020205.1 SANDO
SHI205 AUTOTEAM
STRF526 3EFFE
PRSF526 3EFFE
STR3123 AUTOELECTRO
UD19216S AS-PL
STR72227 WOODAUTO
WOOSTR72227 WOODAUTO
MAV222050 SIOM
F032114675 CARGO
S150.917 PSH

Features

generic brand

Electrical Information
Voltage 12
KW 0.6
Physical Information
A Mount flange 67.00
E Mounting holes M8
E Mounting holes 2 M8
B Drive distance 32.00
F Distance / Back 135.00
G Distance / Front 60.00
H Nbr of teeth 11
I B+ M6
N Gear type Dd
O Distance mm 85.50
P Rotation COUNTER CLOCKWISE
R Total length mm 204.00

Starter for engine hors-bord YAMAHA

Applications Engines :

25 (84-86)

30 (84-86)
C25 (91-97)

C30 (91-97)

C40 (91-97)

Mounting on

Brand Model Typ Year
MARINER 25E 26.2ci-25H.P. 01.1980 - 12.1984
MARINER 25EL 26.2ci-25H.P. 01.1980 - 12.1984
MARINER 30EO 30.3ci-30H.P. 01.1987 - 12.1990
MARINER 30E 30.3ci-30H.P. 01.1980 - 12.1986
MARINER 30ELO 30.3ci-30H.P. 01.1987 - 12.1989
MARINER 30EL 30.3ci-30H.P. 01.1980 - 12.1986
MARINER 40ELHPTO 36.1ci-40H.P. 01.1986 - 12.1989
MARINER 40ELPTO 36.1ci-40H.P. 01.1986 - 12.1989
MARINER 40EL 36.1ci-40H.P. 01.1978 - 12.1985
MARINER 40ELO 36.1ci-40H.P. 01.1986 - 12.1990
MARINER 40EO 36.1ci-40H.P. 01.1986 - 12.1990
MARINER 40E 36.1ci-40H.P. 01.1978 - 12.1985
MERCURY 30EO 30.3ci-30H.P. 01.1987 - 12.1990
MERCURY 30ELO 30.3ci-30H.P. 01.1987 - 12.1990
YAMAHA 25L   01.1984 - 12.1985
YAMAHA CV25EML   01.1990 - 12.1990
YAMAHA C25MSH   01.1993 - 12.1997
YAMAHA 30EL   01.1984 - 12.1986
YAMAHA CV40EL   01.1990 - 12.1990
YAMAHA C40MSH   01.1992 - 12.1997
YAMAHA C40ELR   01.1991 - 12.1997
YAMAHA C25ELH   01.1993 - 12.1997
YAMAHA 25ES   01.1984 - 12.1985
YAMAHA CV25EL   01.1990 - 12.1990
YAMAHA C40MLH   01.1995 - 12.1995
YAMAHA C25MLH   01.1993 - 12.1997
YAMAHA 25S   01.1984 - 12.1985
YAMAHA CV30EL   01.1990 - 12.1990
YAMAHA C30ELR   01.1991 - 12.1997
YAMAHA 30ES   01.1984 - 12.1986
YAMAHA 25EL   01.1984 - 12.1985
YAMAHA C40PLR   01.1992 - 12.1997
YAMAHA C40ESH   01.1997 - 12.1997
YAMAHA C25ELR   01.1991 - 12.1997
