Alternator NEW replacing PRESTOLITE ANB7004 / ANB7003 / ANB7002

Information:

Voltage 28

Amp 22

D = Bracket hole 13.00

G = Belt. adj. bracket hole M12

B = Width/holder arm 15.50

E = Belt. adj. brackethole pos. 60

C = Mount. bracket dist 102.19

H = Pulley dia. 91.60

Pulley dist. 83.30

Grooves/pulley 2

J = Radius 96.00

J = Radius 96.00

Position B + M12

Rotation Cr

Plug no. 1 PL_NA

Fan Without

Pulley Pulley double

R = Total length mm 267.00

        = CATERPILLAR 2p1204 / 2p1698 / 2p5113 / 6n5468

          7s5897 / 9s4070 / 9s4870

= PRESTOLITE ANB7004 / ANB7003 / ANB7002 / ANB7001

ANB6004 / ANB6002 / ANB6001 / 51-212 / 51-178

                NO CORE EXCHANGE NEEDED

                                 TWO YEARS WARRANTY
