w111418

4799367 Iveco
4802574 Fiat
4808500 Fiat
4808502 Fiat
4808507 Fiat
4808509 Iveco
6005717935 Claas
63303290 Magneti Marelli
63307227 Magneti Marelli
63320024 Magneti Marelli
63320024010 Magneti Marelli
63321039 Magneti Marelli
63321039010 Magneti Marelli
63321042 Magneti Marelli
Read more
€89.90 Tax included
Price may vary according to your VAT rate
Last items in stock Fast delivery
Add product to favorites
2-year warranty
No instructions, no return of the old
Secure payments

Features

Information:

Voltage 14

Amp 60

D = Bracket hole M12

G = Belt. adj. bracket hole 11.00

B = Width/holder arm 17.00

E = Belt. adj. brackethole pos. 60

C = Mount. bracket dist 66.00

H = Pulley dia. 90.60

A = Pulley dist. 49.00

Grooves/pulley 1

J = Radius 82.50

J = Radius 79.50

Position B + M6

Rotation Cr

Plug no. 1 PL_NA

Fan Ef

Pulley Pulley

R = Total length mm 165.50

generic brand

= BOSCH 0120489336 / 0120488284 / 0986035760

= ISKRA AAK4530 / 11.201.585

= LUCAS LEA0017 / 61920275 / LRA975

= MAGNETI MARELLI 63321044 / 63321042 / 63320024

= DELCO REMY 19025068 / DRA3355

= FIAT 4799364 / 4808500 / 4808502 / 4808507

0120488284 BOSCH
0120489133 BOSCH
0120489334 BOSCH
0120489335 BOSCH
0120489336 BOSCH
0120489337 BOSCH
0120489876 BOSCH
0120489877 BOSCH
0986035760 BOSCH
105009055 PSH
11040786 EuroTec
111418 Cargo
11201585 MAHLE
12030120 EuroTec
12030970 EuroTec
12031410 EuroTec
12035760 EuroTec
13152 Lester
19025068 DELCO REMY
20100975 PRESTOLITE
220499 PIC
23696 LUCAS
240705 LUCAS
3621SP Spidan
4094 CEVAM
42498240 FIAT
42498504 FIAT
436586 VALEO
4799364 CHRYSLER
4808500 FIAT
4808502 FIAT
4808507 FIAT
4808509 IVECO
56117 EAI
63303290 MAGNETI MARELLI
63307227 MAGNETI MARELLI
63320024 MAGNETI MARELLI
63321039 MAGNETI MARELLI
63321042 MAGNETI MARELLI
63321044 MAGNETI MARELLI
8EL011360761 HELLA
8EL011711011 HELLA
9035760F Friesen
9120690043 BOSCH
933355 EDR
933355X EDR
935760 EDR
ALT1139sa Electrolog
ALT1164sa Electrolog
ALT4050 UNIPOINT
ALT7976SA Electrolog
ALT9006sa Electrolog
ALT9058sa Electrolog
CA642IR HC
DAN2049 DENSO
DAN610 DENSO
DRA3355 DELCO REMY
DRA5760 DELCO REMY
F032UA0009 BOSCH
F032UA0009K2F BOSCH
F042307000 BOSCH
F042A07000 BOSCH
HCA642IR HC
IA0585 MAHLE
L35760 ATL
L60990 ATL
LRA00975 LUCAS
MAN283 MAGNETI MARELLI
MAN286 MAGNETI MARELLI
MG151 MAHLE

                           Fits

Brand Model Typ Year
ALFA ROMEO AR 8 2.4 [8140.21.200D.I.] 04.1985-12.1988
ALFA ROMEO AR 8 2.4 TD [8140.21.200D.I.] 04.1985-12.1989
FIAT Ducato 1.9 Panorama [149B1.000] 07.1990-03.1994
FIAT Ducato 1.9 TD [280A1.000] 03.1989-03.1994
FIAT Ducato 2.5 4x4 [8144.67] 03.1989-08.1990
FIAT Ducato 2.5 4x4 [8144.67] 07.1990-03.1994
FIAT Ducato 1.9 TD Panorama [280A1.000] 07.1990-03.1994
FIAT Ducato 2.5 TD 4x4 [8140.27] 07.1990-03.1994
IVECO 35-8 2.5 [8140.67F.3710] 01.1991-08.1998
IVECO 35-8 2.5 [8140.67F.3711] 01.1991-08.1998
IVECO 35-8 2.5 [8140.67F.3713] 01.1991-08.1998
IVECO 35-8 2.5 [8140.67F.3721] 01.1991-08.1998
IVECO 35-8 2.5 [8140.67F] 01.1989-08.1998
IVECO 35-8 2.5 [8140.67F] 01.1991-08.1998
IVECO 40-10 2.4 [8140.27S] 01.1985-12.1989
IVECO 40-10 2.5 [8140.27.2720] 01.1990-04.1996
IVECO 40-10 2.5 [8140.27.2720] 01.1991-12.1996
IVECO 40-8 2.4 [8140.61.200] 01.1983-06.1989
IVECO 45-10 2.4 [8140.21.200] 01.1985-12.1989
IVECO 45-10 2.5 [8140.27.2720] 01.1991-04.1996
IVECO 45-12 2.5 [8140.47.2711] 06.1990-04.1996
IVECO 45-12 2.5 [8140.47.2721] 06.1990-04.1996
IVECO 49-10 2.4 [8140.21.200] 01.1985-12.1989
IVECO 49-10 2.5 [8140.27.2700] 01.1989-04.1996
IVECO 49-10 2.5 [8140.47R.2790] 01.1989-04.1996
IVECO 49-12 2.5 [8140.47.2711] 06.1990-04.1996
IVECO 49-12 2.5 [8140.47.2721] 06.1990-04.1996
IVECO 59-12 2.5 [8140.47.2700] 05.1991-04.1996
IVECO 59-12 2.5 [8140.47.2711] 05.1991-04.1996
IVECO 30-8 2.5 [8140.07.2700] 01.1989-08.1998
IVECO 30-8 2.5 [8140.07.2700] 01.1992-08.1998
IVECO 30-8 2.5 [8140.07.2712] 01.1989-08.1998
IVECO 30-8 2.5 [8140.67F.3710] 01.1989-08.1998
IVECO 30-8 2.5 [8140.67F.3710] 01.1996-08.1998
IVECO 30-8 2.5 [8140.67F.3711] 01.1989-08.1998
IVECO 30-8 2.5 [8140.67F.3711] 01.1996-08.1998
IVECO 30-8 2.5 [8140.67F.3713] 01.1989-08.1998
IVECO 30-8 2.5 [8140.67F.3713] 01.1996-08.1998
IVECO 30-8 2.5 [8140.67F.3721] 01.1989-08.1998
IVECO 30-8 2.5 [8140.67F.3721] 01.1996-08.1998
IVECO 30-8 2.5 [8140.67F] 01.1989-08.1998
IVECO 30-8 2.5 [8140.67F] 01.1996-08.1998
IVECO 35-10 2.4 [8140.21.200] 01.1985-12.1989
IVECO 35-10 2.5 [8140.47R.2790] 01.1989-12.1996
IVECO 35-10 2.5 [8140.47R.2790] 01.1989-08.1998
IVECO 35-10 2.5 [8140.47R] 01.1989-08.1998
IVECO 35-10 2.5 [8140.97.2781] 01.1989-12.1996
IVECO 35-12 2.5 [8140.47.2700] 01.1990-04.1996
IVECO 35-8 2.5 [8140.07.2700] 01.1989-08.1998
IVECO 35-8 2.5 [8140.07.2700] 01.1991-08.1998
IVECO 35-8 2.5 [8140.07.2712] 01.1989-08.1998
IVECO 35-8 2.5 [8140.07.2712] 01.1991-08.1998
IVECO Daily 2.8 [8140.23.] 11.1997-07.2007
IVECO 35-8 2.5 [8140.67F.3701] 01.1991-08.1998
IVECO Daily 2.8 4x4 [8140.43.] 02.1995-05.1999
