w110645

Remplace

  • Aqua Power 2840, Johnson Electric 0814240, Original Reference Number 0814240, 4786240, Outboard Marine Corp (OMC) 387094, 395207, 585062, 586288, 777693, 778992, Prestolite 20513501TBA, 46-2387, MJL4005, United Technologies 0814240-M030SM, 0814240MO30SM, 4786240-M030SM, 4786240MO30SM, SM08142





Read more
€89.90 Tax included
Price may vary according to your VAT rate
Fast delivery
Add product to favorites
2-year warranty
No instructions, no return of the old
Secure payments

Références

5709 LESTER
SAB0003 ARROWHEAD
71-06-5294 WILSON
2-2074-UT WAI / TRANSPO
5709N WAI / TRANSPO
10439034 ALANKO
120.011.083.200 PSH
3110260 HENKEL PARTS
110645 CARGO
0814240M030SM UNITED TECHNOLOGIES
0814240MO30SM UNITED TECHNOLOGIES
462387 PRESTOLITE
4786240 UNITED TECHNOLOGIES
4786240MO30SM UNITED TECHNOLOGIES
MJL4005 PRESTOLITE
OMS109 PRESTOLITE
SM08142 UNITED TECHNOLOGIES
SM47862 UNITED TECHNOLOGIES
STR1061 UNIPOINT
STR88237 WOODAUTO
WOOSTR88237 WOODAUTO
387094 OMC
395207 OMC
585062 OMC
586288 OMC
711D1130C OMC
UD13720S AS-PL
F032110645 CARGO
S129.598 PSH

Features

Information:

Voltage 12

KW 0.9

A = Mount flange 63.50

B = Drive distance 43.50

F = Distance / Back 176.00

G = Distance / Front 77.50

H = Nbr of teeth 8

B+ 1/4" UNC

Gear type Dd

Rotation COUNTER CLOCKWISE

Nbr of mounting holes 1 (0)

generic brand

                                   NO CORE EXCHANGE NEEDED

                                                             TWO YEARS WARRANTY

Mounting on

Brand Model Typ Year
EVINRUDE E150TX 2.5 149.4ci-150H.P. 01.1984 - 12.1991
EVINRUDE E150CX 2.5 149.4ci-150H.P. 01.1988 - 12.1991
EVINRUDE E150TL 2.5 149.4ci-150H.P. 01.1984 - 12.1991
EVINRUDE E150TRX 2.5 149.4ci-150H.P. 01.1980 - 12.1983
EVINRUDE E 150 2.5 149.4ci-150H.P. 01.1977 - 12.1979
EVINRUDE E150STL 2.5 149.4ci-150H.P. 01.1984 - 12.1991
EVINRUDE E150TRL 2.5 149.4ci-150H.P. 01.1980 - 12.1983
EVINRUDE E155WTX 2.5 149.4ci-155H.P. 01.1985 - 12.1995
EVINRUDE E155WTL 2.5 149.4ci-155H.P. 01.1985 - 12.1995
EVINRUDE E175TRX 2.5 149.4ci-175H.P. 01.1980 - 12.1983
EVINRUDE E175TRL 2.5 149.4ci-175H.P. 01.1980 - 12.1983
EVINRUDE E175 2.5 149.4ci-175H.P. 01.1977 - 12.1979
EVINRUDE E185TX 2.5 149.4ci-185H.P. 01.1984 - 12.1985
EVINRUDE E185TL 2.5 149.4ci-185H.P. 01.1984 - 12.1985
EVINRUDE E200TRX 2.5 149.4ci-200H.P. 01.1980 - 12.1983
EVINRUDE E 200 2.5 149.4ci-200H.P. 01.1977 - 12.1979
EVINRUDE E200TRL 2.5 149.4ci-200H.P. 01.1980 - 12.1983
EVINRUDE E175TL 2.6 160.3ci-175H.P. 01.1986 - 12.1989
EVINRUDE E175STL 2.6 160.3ci-175H.P. 01.1990 - 12.1991
EVINRUDE E175TX 2.6 160.3ci-175H.P. 01.1985 - 12.1991
EVINRUDE E200TX 2.7 160.3ci-200H.P. 01.1987 - 12.1987
EVINRUDE E200STL 2.7 160.3ci-200H.P. 01.1986 - 12.1987
EVINRUDE E225PX 2.7 160.3ci-225H.P. 01.1987 - 12.1987
EVINRUDE E225CL 2.7 160.3ci-225H.P. 01.1987 - 12.1987
EVINRUDE E225TX 2.7 160.3ci-225H.P. 01.1986 - 12.1987
EVINRUDE E225PL 2.7 160.3ci-225H.P. 01.1987 - 12.1987
EVINRUDE E225PTX 2.7 160.3ci-225H.P. 01.1986 - 12.1986
EVINRUDE E225 2.7 160.3ci-225H.P. 01.1977 - 12.1979
EVINRUDE E225TL 2.7 160.3ci-225H.P. 01.1986 - 12.1987
EVINRUDE E225CX 2.7 160.3ci-225H.P. 01.1987 - 12.1987
EVINRUDE E225PTL 2.7 160.3ci-225H.P. 01.1986 - 12.1986
EVINRUDE E235TL 2.7 160.3ci-235H.P. 01.1984 - 12.1985
EVINRUDE E235TRX 2.7 160.3ci-235H.P. 01.1980 - 12.1983
EVINRUDE E235STL 2.7 160.3ci-235H.P. 01.1984 - 12.1985
EVINRUDE E235TRL 2.7 160.3ci-235H.P. 01.1980 - 12.1983
EVINRUDE E235TX 2.7 160.3ci-235H.P. 01.1984 - 12.1985
EVINRUDE E235 2.7 160.3ci-235H.P. 01.1977 - 12.1979
JOHNSON 150TX 149.4ci-150H.P. 01.1980 - 12.1991
JOHNSON 150CX 149.4ci-150H.P. 01.1988 - 12.1991
JOHNSON 150TL 149.4ci-150H.P. 01.1980 - 12.1991
JOHNSON 150TRX 149.4ci-150H.P. 01.1983 - 12.1983
JOHNSON 150 149.4ci-150H.P. 01.1977 - 12.1979
JOHNSON 150STL 149.4ci-150H.P. 01.1984 - 12.1990
JOHNSON 150TRL 149.4ci-150H.P. 01.1983 - 12.1983
JOHNSON 155WTL 149.4ci-155H.P. 01.1985 - 12.1992
JOHNSON 155WTLZ 149.4ci-155H.P. 01.1989 - 12.1989
JOHNSON 155WTXM 149.4ci-155H.P. 01.1988 - 12.1988
JOHNSON 155CWTX 149.4ci-155H.P. 01.1987 - 12.1987
JOHNSON 155WTLM 149.4ci-155H.P. 01.1988 - 12.1988
JOHNSON 155WTX 149.4ci-155H.P. 01.1985 - 12.1992
JOHNSON 155CTL 149.4ci-155H.P. 01.1987 - 12.1987
JOHNSON 155WTXZ 149.4ci-155H.P. 01.1989 - 12.1989
JOHNSON 175TX 149.4ci-175H.P. 01.1980 - 12.1981
JOHNSON 175TXL 149.4ci-175H.P. 01.1982 - 12.1982
JOHNSON 175TRX 149.4ci-175H.P. 01.1983 - 12.1983
JOHNSON 175 149.4ci-175H.P. 01.1977 - 12.1979
JOHNSON 175TL 149.4ci-175H.P. 01.1980 - 12.1982
JOHNSON 175TRL 149.4ci-175H.P. 01.1983 - 12.1983
JOHNSON 185TX 149.4ci-185H.P. 01.1984 - 12.1985
JOHNSON 185TL 149.4ci-185H.P. 01.1984 - 12.1985
JOHNSON 200TRL 149.4ci-200H.P. 01.1983 - 12.1983
JOHNSON 200 149.4ci-200H.P. 01.1977 - 12.1979
JOHNSON 200TX 149.4ci-200H.P. 01.1980 - 12.1981
JOHNSON 200TL 149.4ci-200H.P. 01.1980 - 12.1982
JOHNSON 200TRX 149.4ci-200H.P. 01.1983 - 12.1983
JOHNSON 200TXL 149.4ci-200H.P. 01.1982 - 12.1982
JOHNSON 175STL 160.3ci-175H.P. 01.1990 - 12.1991
JOHNSON 175TL 160.3ci-175H.P. 01.1986 - 12.1989
JOHNSON 175TX 160.3ci-175H.P. 01.1986 - 12.1991
JOHNSON 200STL 160.3ci-200H.P. 01.1986 - 12.1986
JOHNSON 225PTX 160.3ci-225H.P. 01.1986 - 12.1986
JOHNSON 225 160.3ci-225H.P. 01.1977 - 12.1979
JOHNSON 225TL 160.3ci-225H.P. 01.1986 - 12.1986
JOHNSON 225TX 160.3ci-225H.P. 01.1986 - 12.1986
JOHNSON 225PTL 160.3ci-225H.P. 01.1986 - 12.1986
JOHNSON 235TRL 160.3ci-235H.P. 01.1983 - 12.1983
JOHNSON 235TX 160.3ci-235H.P. 01.1980 - 12.1985
JOHNSON 235TL 160.3ci-235H.P. 01.1980 - 12.1985
JOHNSON 235TRX 160.3ci-235H.P. 01.1983 - 12.1983
JOHNSON 235TXL 160.3ci-235H.P. 01.1982 - 12.1982
JOHNSON 235STL 160.3ci-235H.P. 01.1984 - 12.1985
JOHNSON 225PX 165.0ci-225H.P. 01.1987 - 12.1987
JOHNSON 225CL 165.0ci-225H.P. 01.1987 - 12.1987
JOHNSON 225TL 165.0ci-225H.P. 01.1987 - 12.1987
JOHNSON 225PL 165.0ci-225H.P. 01.1987 - 12.1987
JOHNSON 225TX 165.0ci-225H.P. 01.1987 - 12.1987
JOHNSON 225CX 165.0ci-225H.P. 01.1987 - 12.1987
