Alternator replacing A007T03277 / A007T03277A / 00591-33580-81 / 00591-55973-81
Alternator NEW replacing :
CLARK 7000215, HYSTER 1361853, 1450928, 3068342, 3114961, 3123908, 800045600
MAZDA S5SN-18-300, S5SN-18-300A, S5SN18-300, SS5SN178-300
Yale 1500145-04, 2690027-70, 5059605-60, 5059765-79, 5800009-90, 8000456-00, 9019488-01
NO CORE EXCHANGE NEEDED
TWO YEARS WARRANTY
More info
Information:
Electrical Information | ||
|---|---|---|
| Voltage | 14 | |
| Amp | 40 | |
| Plug type | W | |
Physical Information | ||
|---|---|---|
| D | Bracket hole | 10.00 |
| G | Belt. adj. bracket hole | M8 |
| B | Width/holder arm | 13.00 |
| E | Belt. adj. brackethole pos. | 60 |
| C | Mount. bracket dist | 81.50 |
| H | Pulley dia. | 74.00 |
| A | Pulley dist. | 42.00 |
| i | Grooves/pulley | 1 |
| j | Radius | 77.00 |
| j | Radius 2 | 77.00 |
| k | Position B + | M6 |
| n | Rotation | CW |
| o | Plug no. 1 | PL09 |
| R | Total length mm | 161.00 |
Generic Brand
Replacing | |
|---|---|
| 00591-33580-81 | TOYOTA |
| 00591-55973-81 | TOYOTA |
| 1500145-04 | YALE |
| 2690027-70 | YALE |
| 5059605-60 | YALE |
| 5059765-79 | YALE |
| 5800009-90 | YALE |
| 8000456-00 | YALE |
| 9019488-01 | YALE |
| A007T03277 | MITSUBISHI |
| A007T03277A | MITSUBISHI |
| a7t03277 | MITSUBISHI |
| a7t03277a | MITSUBISHI |
| LRA002043 | LUCAS |
| S5SN-18-300 | MAZDA |
| S5SN-18-300A | MAZDA |
CLARK 7000215, HYSTER 1361853, 1450928, 3068342, 3114961, 3123908, 800045600
Jungheinrich 14485060, MAZDA S5SN-18-300, S5SN-18-300A, S5SN18-300, SS5SN178-300
MITSUBISHI A007T03277, A007T03277A
TOYOTA 00591-33580-81, 00591-55973-81, Yale 1500145-04, 2690027-70, 5059605-60, 5059765-79, 5800009-90, 8000456-00, 9019488-01
Mounted on :
forklift
HYSTER (1992-2006)
MITSUBISHI
Sumitomo Yale (1992-2002)
Yale (1985-2006)
NO CORE EXCHANGE NEEDED
TWO YEARS WARRANTY
