Alternateur remplace Bosch 0120488251 / 0120489152 / 0120489219
Alternateur NEUF remplace AAK4155 / 11201329
Bosch 0120488251 / 0120489152 / 0120489219 / 0120489212 / 0986035630 / 0986035631
63305802 / 63305822 / 63305832 / 63305842 / 63307802 / 63307822 / 63307832 / 63320015
PAS DE CONSIGNE NI DE RETOUR DE L'ANCIEN
GARANTIE 2 ANS
Caractéristiques
Caractéristiques :
Spécifications électriques | ||
|---|---|---|
| Voltage | 14 | |
| Amp | 65 | |
Spécifications physiques | ||
|---|---|---|
| D | Diamétre du trou | 12.50 |
| G | Diamétre trou de la patte | 11.00 |
| B | Largeur des bras | 17.00 |
| E | Angle pâte tendeur | 60 |
| C | Dist. entre support | 64.50 |
| H | Poulie dia. | 73.50 |
| A | Dist. poulie | 49.50 |
| i | Rainures de la poulie | 1 |
| j | Radius | 85.00 |
| j | Radius 2 | 81.00 |
| k | Position B + | M6 |
| n | Rotation | Cr |
| R | Longueur totale mm | 166.50 |
marque adaptable
= référence :
0108447 | KHD |
|---|---|
0120488225 | Bosch |
0120488250 | Bosch |
0120488251 | Bosch |
0120489152 | Bosch |
0120489153 | Bosch |
0120489212 | Bosch |
0120489219 | Bosch |
0120489338 | Bosch |
038522068A | Chrysler |
063305802 | Magneti Marelli |
063307801 | Magneti Marelli |
063307802 | Magneti Marelli |
063320049 | Magneti Marelli |
063320049010 | Magneti Marelli |
063321099 | Magneti Marelli |
0763320049 | Magneti Marelli |
0986035630 | Bosch Exchange |
0986035631 | Bosch Exchange |
10441586 | Alanko |
10443092 | Alanko |
105001065 | PSH |
111166 | Cargo |
11201329 | Mahle |
12035630 | EuroTec |
12037150 | EuroTec |
19025064 | Delco |
20130207 | Prestolite |
218111652 | DRI |
2565994 | Valeo |
2565995 | Valeo |
281734 | Elstock |
281875 | Elstock |
2943925 | Fiat |
294392500 | Same |
30355RI | DAS |
3409SP | Spidan |
35962 | Sparex |
38522068A | Chrysler |
436237 | Valeo |
440502 | Logistik |
441586 | Alanko |
443092 | Alanko |
46231758 | Fiat |
4763249 | KHD |
4772668 | Alfa Romeo |
4798447 | Iveco |
4798449 | Iveco |
4798489 | Fiat |
4808506 | Fiat |
4808511 | Fiat |
4849155 | Fiat |
4849157 | Fiat |
55574 | EAI |
55631 | EAI |
63305802 | Magneti Marelli |
63305822 | Magneti Marelli |
63305832 | Magneti Marelli |
63305842 | Magneti Marelli |
63307801 | Magneti Marelli |
63307802 | Magneti Marelli |
63307822 | Magneti Marelli |
63307832 | Magneti Marelli |
63307862 | Magneti Marelli |
63320015 | Magneti Marelli |
63320015010 | Magneti Marelli |
63320049 | Magneti Marelli |
63320049010 | Denso |
63320049SEL | +line |
63321020 | Magneti Marelli |
63321022 | Magneti Marelli |
63321031 | Denso |
63321031010 | Magneti Marelli |
63321099 | Magneti Marelli |
63321099010 | Magneti Marelli |
63321146 | Magneti Marelli |
72735520 | Mahle |
77452410 | Fiat |
89212230 | PowerMax |
9035630 | Friesen |
9035630F | Friesen |
943320049 | Magneti Marelli |
943321020 | Magneti Marelli |
943321021 | Magneti Marelli |
A129658 | Short code |
A145982 | Short code |
A158777 | Short code |
A355 | Customized |
A4122 | AS-PL |
A4122S | AS-PL |
A9083 | AS-PL |
AAK4155 | Mahle |
AAK4176 | Mahle |
AGN903550 | ADI |
AGN903552 | ADI |
AGN903555 | ADI |
AL00931 | TMI |
AL925X | Bosch (USA) |
ALT12129 | Wood Auto |
ALT26002 | Wood Auto |
ALT4040 | Unipoint |
ALTH225 | Unipoint |
CA355IR | HC-Parts |
DAN2044 | Denso |
DAN604 | Denso |
DRA5630 | Remy |
F042A0H225 | Bosch |
HCA355IR | HC-Parts |
IA0329 | Mahle |
IR7150 | Protech |
JFWZ15A | Other |
JFWZ15B | Other |
JFWZ15Y | Other |
L35630 | ATL |
LETIA0329 | Wood Auto |
LRA00752 | Lucas |
LRA00929 | Lucas |
LRA01352 | Lucas |
LRA752 | Lucas |
LRA929 | Lucas |
MAHMG521 | Wood Auto |
MAN771 | Magneti Marelli |
MAR274 | Magneti Marelli |
MG521 | Mahle |
PRE20130207 | Wood Auto |
RNL63320049 | RNL |
RNL63320049V2 | RNL |
RNLMG521 | RNL |
VLN90355 | ADI |
W27117 | Van Heck |
WOOALT26002 | Wood Auto |
WSD238021 | Stabeco |
Montage sur :
FIAT : 131 - ARGENTA - CROMA - DUCATO
FIAT Agriculture : 100 - 110 - 115 - 130 - 140 - 160 - 180
LAMBORGHINI
| 100 | 190 | 6.0 | Diesel | 1992 01 | 1999 12 | 1000.6 | Diesel | 0 | 0 | Rasing | 0 | 6 | |
| 100 | 115 | 6.0 | Diesel | 1989 12 | 1999 12 | 1000.6 | Diesel | 0 | 0 | Formula | 0 | 6 | |
| 100 | 135 | 6.0 | Diesel | 1989 12 | 1999 12 | 1000.6 | Diesel | 0 | 0 | Formula | 0 | 6 | |
| 100 | 165 | 6.0 | Diesel | 1991 05 | 1999 12 | 1000.6 | Diesel | 0 | 0 | Racing | 0 | 6 | |
| 600 Series | Various Models | - | - | 0 | 0 | 0 | |||||||
| 900 Series | Various Models | - | - | 0 | 0 | 0 |
ALFA ROMEO
| Alfa 33 | Alfa 33 | 1.8 | Diesel | 1986 01 | 1990 06 | VM82A | TD | 54 | 73 | Hayon | 1779 | 3 | 905 | |
| Alfa 33 | Alfa 33 | 1.8 | Diesel | 1986 01 | 1989 12 | VW82A | TD | 62 | 84 | Break | 1779 | 4 | 905 | |
| Alfa 75 | Alfa 75 | 2.0 | Diesel | 1985 05 | 1992 09 | VM80A | TD | 70 | 95 | 1995 | 4 | 162 | ||
| Alfa 75 | Alfa 75 | 2.4 | Diesel | 1989 01 | 1992 02 | VM81A | TD | 82 | 112 | 2393 | 4 | 162 |
LANCIA
| Thema | Thema | 2.5 | Diesel | 1984 11 | 1988 09 | 8144.91 | TD | 74 | 101 | 2445 | 4 | |||
| Thema | Thema | 2.5 | Diesel | 1988 06 | 1992 05 | 8144.97 | TDS | 85 | 115 | 2499 | 4 | 834 | ||
| Thema | Thema | 2.5 | Diesel | 1988 05 | 1992 07 | 8144.97S | TD |
